Gold-silver tellurides

- gold ores from historic mines of Colorado, U.S.A., II

[193 kb]

Figure 1. Small rock chips of telluride ores from the old Cresson mine at Cripple Creek, Teller county, Colorado. On the left is a fine-grained alkalic igneous rock (phonolite), a sawn piece (sample 1824) of material collected by Kenny Mumford in 1956 (purchased from David Shannon Minerals in 1997). The two smaller, angular pieces (sample 1665) of silicified phonolite were collected in 1992 by Brad Bowman when the old mine dumps were being reworked for the gold content of the tailings (from David Shannon Minerals, Tucson show, 1995). The gold telluride calaverite, AuTe2 occurs as elongate silvery-grey crystals in the grey feldspathic host rock.

"Rock of the Month #161, posted for November 2014" ---

Gold-silver telluride minerals, and gold ores from Colorado, II

The tellurides shown in this item occur as relatively coarse, lustrous grains that may be visible to the native eye. Tellurium occurs as a native element and a wide range of tellurides, reduced compounds with such metals as Cu, Bi, Ag, Pb, Hg, Fe, Ag, Pt and Pd. The optical properties of 26 tellurides were compiled by Uytenbogaardt and Burke (1971, pp.233-253). The tellurides of the platinum group elements, as with most discrete minerals of the PGE, are generally microscopically small, <0.05 mm in diameter. Gold deposits associated with alkalic igneous bodies commonly contain tellurides, including the gold-silver tellurides petzite, sylvanite and krennerite, and the Au telluride calaverite.

This month's article is an extension of the recent introduction to tellurides from Colorado. To read more on a different, Pb-Ag-Bi telluride association, see Rock of the Month 67 on rucklidgeite.

Cripple Creek (Carnein and Bartos, 2005) is one of many gold camps worldwide with appreciable gold production from telluride ores. Many telluride minerals have been described from mesothermal to epithermal gold vein deposits around Kalgoorlie in Western Australia (Stillwell, 1953; Shackleton et al., 2003); Kirkland Lake, Ontario (Todd, 1928); and at the Emperor mine in Fiji (Pals and Spry, 2003). Many American occurrences are very well-documented, from such early works as Genth (1868) and Silliman (1874) to more recent observations (e.g., Geller, 1993). The geological and mineralogical literature for such a relatively obscure element as tellurium is surprisingly extensive. As of 01 November 2014, the MINLIB bibliography had 1,354 records of Te and tellurides, from 1849 to the present, including 118 on calaverite, 85 on sylvanite and 20 on the Cu telluride, rickardite.

Tellurides tend to occur as small (mm-scale and smaller) crystals, but the larger end of the size distribution is, not surprisingly, found in high-end private and museum collections. Examples from Cripple Creek include calaverite and sylvanite (Barlow et al., 1996; Carnein and Bartos, 2005, pp.163-167,180; Geffner, 2013) and even pseudomorphs of the nickel telluride melonite replacing calaverite (Carnein and Bartos, 2005, p.174; Wilson, 2009, p.77).

[145 kb] [183 kb]

Figure 2. Photomicrographs of sample 1665. Left: an elongate mass of creamy calaverite plates small, equant, euhedral pyrite grains within poorly-reflective gangue minerals. Right: in this view the opaque ore minerals appear in outline, adjacent to coarse, strained quartz and K-feldspar, in (top right) the very fine-grained feldspathic matrix. Nominal magnification 100X, long-axis field of view 0.9 mm, plane-polarized reflected light and (right) crossed-polarized transmitted light.

[209 kb] [158 kb]

Figure 3. Photomicrographs of samples 1665 and (right) 1445. Left: carbonate and quartz inclusions in a small K-feldspar phenocryst, in the fine-grained trachytic-textured groundmass of the rock. Right: a thin section of a chip (sample 1445) from the nearby Portland mine. This sample is labelled as "sylvanite in phonolite breccia". It was purchased from David New in 1992. The rock is a medium to pale grey breccia with pale phonolite clasts in a dark cement containing shiny ore minerals. Small quartz-lined vugs host discrete silvery-grey platy crystals of the monoclinic telluride sylvanite, (Au,Ag)2Te4. This image shows one of the scattered, large (up to 0.8 mm) crystals of shiny sylvanite, partially overgrowing small, equant, subhedral to euhedral crystals of fractured pyrite in a matrix of strained quartz. Nominal magnification 50X, long-axis field of view 1.7 mm, in crossed-polarized transmitted and (right) plane-polarized reflected light.


Barlow,FJ, Jones,RW and LaBerge,GL (editors) (1996) The F. John Barlow Mineral Collection. Sanco Publishing, Appleton, WI, 408pp.

Carnein,CR and Bartos,PJ (2005) The Cripple Creek mining district. Mineral.Record 36, 143-185.

Geffner,P (2013) Mineral collections of the Crystal Gazers and friends. Mineral.Record 44 no.6, supplement, 136pp., November.

Geller,BA (1993) Mineral Studies in the Boulder Telluride Belt. PhD Thesis, 2 volumes, 731pp., University of Colorado, Boulder.

Genth,FA (1868) Contributions to mineralogy. Amer.J.Sci. ser.2, 45, 305-321.

Pals,DW and Spry,PG (2003) Telluride mineralogy of the low-sulfidation epithermal Emperor gold deposit, Vatukoula, Fiji. Mineral.Petrol. 79, 285-307.

Shackleton,JM, Spry,PG and Bateman,R (2003) Telluride mineralogy of the Golden Mile deposit, Kalgoorlie, Western Australia. Can.Mineral. 41, 1503-1524.

Silliman,B (1874) Tellurium ores of Colorado. Amer.J.Sci. 108, 25-29.

Stillwell,FL (1953) Tellurides in Western Australia. In `Geology of Australian Ore Deposits' (Edwards,AB editor), Australasian Institute of Mining and Metallurgy, 1290pp., 119-127.

Todd,EW (1928) Kirkland Lake gold area: a detailed study of the central ore zone and vicinity. ODM Ann.Rep. 37 part 2, 176pp.

Uytenbogaardt,W and Burke,EAJ (1971) Tables for Microscopic Identification of Ore Minerals. Elsevier, 2nd revised edition, 430pp.

Wilson,WE (editor) (2009) Private Mineral Collections in Texas. Mineral.Record 40 no.1, supplement, 180pp., January.

Graham Wilson, 01,31 October 2014, 01-02 November 2014.
